What is Nitinol Tube?
High-strength Nitinol tubes are an essential component in the design of advanced medical devices, particularly in micro-invasive procedures. Made from a unique titanium-nickel alloy, these tubes offer exceptional strength, flexibility, and biocompatibility, making them ideal for applications such as guidewires and filters used in minimally invasive surgeries. Due to their superelastic properties and corrosion resistance, Nitinol tubes are becoming increasingly popular in the medical industry, providing medical professionals with tools that ensure precise and reliable performance in delicate procedures.
Tubing Actual Performance Af Temperature | For finished tubes with an outer diameter of 0.25-9.0mm, after cutting a section of the tube, the actual recovery temperature can be tested using the bending recovery method specified in ASTM F2082/F2082M-16. |
| Surface Condition | Outer Surface: Oxidized state, ground state Inner Surface: Clean state |
| Tubing Length | Length can be precisely specified or arbitrarily specified; for arbitrary lengths, the maximum and minimum lengths can be negotiated with sales or technical personnel. |
| Straightness | The requirements and test methods for straightness can be agreed upon with sales or technical personnel. |
| Internal and External Surface Defects | The requirements for surface defects can be agreed upon with sales or technical personnel. |
| Typical Applications | Medical: Hypo tubes, camera tubes, stents, baskets, catheters |
Features of Nitinol Tube
Superelasticity: Nitinol's superelastic nature allows the tubes to maintain their shape and functionality under various stress conditions, making them perfect for dynamic applications like guidewires and filters that require frequent manipulation.
Corrosion Resistance: Nitinol exhibits excellent resistance to corrosion, even in challenging environments such as body fluids, making it an ideal material for long-term use in medical devices.
Biocompatibility: The biocompatible properties of Nitinol ensure that these tubes are safe for use within the human body, reducing the risk of allergic reactions or adverse tissue responses.
Flexibility and Strength: Nitinol tubes offer a unique combination of flexibility and strength, allowing them to bend without breaking while maintaining their structural integrity, which is crucial in minimally invasive procedures.
Customization: These tubes are available in a range of sizes, thicknesses, and lengths to suit various applications, from micro-invasive guidewires to specialized filters.
Pipe specifications
| Tubing Inner Diameter (mm) | Wall Thickness (mm) | Tolerance Range (mm) | Length (mm) |
| 9-4 | 4-0.5 | ±0.035 | 500 |
| 4-2 | 0.5-0.2 | ±0.030 | 500 |
| 2-1 | 0.3-0.15 | ±0.020 | Above 1000 |
| 1-0.5 | 0.2-0.1 | ±0.010 | 1000-2000 |
| 0.5-0.25 | 0.1-0.05 | ±0.005 | 1000-2000 |
*Can be adjusted according to customer requirements
Advantages of Nitinol Tube
Enhanced Precision in Procedures: The flexibility and durability of Nitinol tubes make them highly effective in guiding surgical instruments with precision in minimally invasive surgeries, improving the outcomes of complex procedures.
High Fatigue Resistance: Nitinol tubes are designed to endure repeated cycles of stress without failure, making them ideal for devices like guidewires that experience frequent flexing during insertion and manipulation.
Reduced Complications: Due to their biocompatibility and corrosion resistance, Nitinol tubes reduce the risk of inflammation or infection, improving patient recovery time and minimizing complications.
Adaptability: With customization options for various dimensions, Nitinol tubes can be tailored to meet the specific needs of different medical devices, ensuring that they work effectively for guidewires, filters, and other critical tools.
Lightweight and Easy Handling: Nitinol tubes are lighter than many other metal alloys, enhancing the ease of handling and maneuverability in delicate medical procedures, while maintaining robust performance.
Applications of Nitinol Tube
High-strength Nitinol tubes are used extensively in micro-invasive medical devices, including:
Guidewires: Nitinol tubes are commonly used to manufacture guidewires, offering exceptional flexibility, strength, and responsiveness. These guidewires are critical for navigating complex anatomical structures with precision during procedures like angioplasty or catheterization.
Filters: Nitinol’s strength and corrosion resistance make it ideal for creating medical filters, such as those used in blood filtration or embolism prevention devices. These filters need to withstand blood flow and physical stress while maintaining integrity.
Stents: In addition to guidewires and filters, Nitinol tubes are used to create self-expanding stents. The material’s ability to change shape when exposed to body temperature helps stents expand once deployed, providing effective treatment for blockages.
Catheters: Nitinol tubes also play a vital role in catheter production, offering flexibility and robustness while maintaining a lightweight profile, ideal for long-term placement in the human body.
ABOUT US
Victory Alloy Co., Ltd. is a professional manufacturer specializing in medical alloy materials, with a dedicated focus on the research, development and production of high-performance biomedical alloys.
Our primary product range includes medical-grade titanium alloys, Nitinol (nickel-titanium alloy), cobalt-chromium (CoCr) alloys, platinum-iridium (Pt-Ir) alloys, and medical stainless steel. These high-quality alloys are widely applied in a broad spectrum of medical fields, such as cardiovascular stents, orthopedic implants, interventional guidewires, dental implants, surgical instruments, and disposable medical auxiliary devices. Boasting outstanding biocompatibility, strong corrosion resistance and excellent mechanical properties, our products have won consistent praise from customers across the board.
Client Visits
We welcome client visits to showcase our manufacturing and testing processes. Clients can explore our facility, discuss specific needs, and learn about our quality control methods. Our team ensures a personalized experience to meet your exact requirements for medical applications.
Our Factory
Quality Testing of the Product
Our product undergoes strict testing for tensile strength, corrosion resistance, and biocompatibility to ensure reliable performance in joint implants. We use advanced methods to verify its safety and durability, and all products meet international medical standards for consistent, long-term use in the body.
FAQ
Who is your company?
We are a leading supplier of high-quality Nitinol alloy wire, specializing in providing durable, biocompatible materials for orthopedic joint replacements and other medical applications.How can I contact your company?
Phone: +86 132 1868 0935
Whatsapp: +86 13218680935
Email: victory@dlx-alloy.com
What makes Nitinol tubes ideal for guidewires?
Nitinol tubes are perfect for guidewires due to their superelasticity, flexibility, and strength, allowing them to navigate complex anatomy without breaking or losing shape.Are Nitinol tubes resistant to corrosion in the human body?
Yes, Nitinol tubes exhibit excellent corrosion resistance, ensuring reliable performance even when exposed to body fluids for extended periods.Can I customize Nitinol tubes for my medical device needs?
Absolutely. We offer a wide range of customization options, including varying sizes, wall thicknesses, and lengths to meet the specific requirements of your device.How do Nitinol tubes improve patient outcomes in minimally invasive procedures?
Nitinol tubes enhance precision, reduce complications, and improve flexibility, leading to better patient outcomes and faster recovery times in micro-invasive procedures.
