Introduction of Titanium Alloy Tube
Titanium alloy tubes have become an essential material in modern dentistry, particularly in providing support for dental bridges. As a critical component of restorative dental procedures, titanium tubes ensure that dental bridges remain secure, durable, and reliable throughout the treatment process. These tubes are widely recognized for their strength, corrosion resistance, and biocompatibility, making them an ideal choice for dental professionals seeking to provide their patients with high-quality, long-lasting results.
Titanium tubes offer superior mechanical properties, including high tensile strength and flexibility, which are crucial in the construction of stable dental bridges. Additionally, their resistance to corrosion ensures that they maintain their integrity in the challenging oral environment, where moisture and food particles can degrade other materials over time.
| China | Classification | UK | Russia | Japan |
| TA1 | Commercial Pure Titanium | GR1 | BT1-00 | TP270 |
| TA2 | Commercial Pure Titanium | GR2 | BT1-0 | TP340 |
| TA3 | Commercial Pure Titanium | GR3 | TP450 | |
| TA4 | Commercial Pure Titanium | GR4 | TP550 | |
TC4 | Ti-6AI-4V | GR5 | BT6 | TAP6400 |
| TA7 | GR6 | |||
| TA9 | Ti-0.2Pd | GR7 | TP340Pb | |
TA18 | Ti-3Al-2.5V | GR9 | 0T4-1B | TAP3250 |
| TA9-1 | GR11 | |||
| TA10 | Ti-0.3Mo-0.8Ni | GR12 | ||
| TB5 | Ti-15V-3Al-3Gr-3Sn | Ti-15333 | ||
| TC4ELI | Ti-6AI-4VELI | GR23 |
Features of Titanium Alloy Tube
Biocompatibility: Titanium is highly biocompatible, meaning it integrates well with human bone and tissue. This reduces the risk of allergic reactions and ensures a comfortable, long-term solution for dental bridge support.
Corrosion Resistance: Titanium tubes are highly resistant to corrosion, making them ideal for the wet, acidic environment of the mouth. They won’t degrade or lose their structural integrity over time, ensuring dental bridges remain secure.
Lightweight yet Strong: Despite their strength, titanium alloy tubes are lightweight, offering a comfortable solution for dental bridge support without adding unnecessary bulk to the appliance.
Durable and Long-Lasting: Titanium is known for its excellent durability. Titanium tubes used in dental bridges ensure that the bridge stays stable and secure for many years, providing patients with lasting results.
Precise Customization: Titanium tubes can be precisely engineered to fit the specific requirements of each dental bridge design, ensuring a perfect fit and optimal support for the dental structure.
| Mechanical Properties | |||||||
| Grade | Condition | Tensile Strength | Yield Strength | Elongation | Reductionof Area | ||
| Ksi | Mpa | Ksi | Mpa | % | |||
| ≥ | |||||||
GR1 | Annealed | 35 | 240 | 25 | 170 | 24 | 30 |
| GR2 | 50 | 345 | 40 | 275 | 20 | 30 | |
| GR3 | 65 | 450 | 55 | 380 | 18 | 30 | |
| GR4 | 80 | 550 | 70 | 483 | 15 | 25 | |
| GR5 | 130 | 895 | 120 | 828 | 10 | 25 | |
| GR6 | 120 | 828 | 115 | 483 | 15 | 25 | |
| GR7 | 50 | 345 | 40 | 275 | 20 | 30 | |
| GR9 | 90 | 620 | 70 | 483 | 15 | 25 | |
| GR11 | 35 | 240 | 25 | 170 | 24 | 30 | |
| GR12 | 70 | 483 | 50 | 345 | 18 | 25 | |
| GR23(Ti-6AL-4VELI) | 125 | 860 | 115 | 795 | 10 | 25 | |
Titanium Alloy Grade Composition Table
| Grade | C ≤ | O ≤ | N ≤ | H ≤ | Fe ≤ | Al | V | Pd | Ni | Mo | Average of Other Elements | Total of Other Elements |
| Gr1 | 0.08 | 0.18 | 0.03 | 0.015 | 0.2 | - | - | - | - | - | 0.1 | 0.4 |
| Gr2 | 0.08 | 0.25 | 0.03 | 0.015 | 0.3 | - | - | - | - | - | 0.1 | 0.4 |
| Gr4 | 0.08 | 0.25 | 0.03 | 0.015 | 0.3 | - | - | - | - | 0.1 | 0.4 | |
| Gr5 | 0.08 | 0.2 | 0.05 | 0.015 | 0.4 | 5.5~6.75 | 3.5~4.5 | - | - | - | 0.1 | 0.4 |
| Gr7 | 0.08 | 0.25 | 0.03 | 0.015 | 0.3 | - | - | 0.12~0.25 | 0.12~0.25 | - | 0.1 | 0.4 |
| Gr9 | 0.08 | 0.15 | 0.03 | 0.015 | 0.25 | 2.5~3.5 | 2.0~3.0 | - | - | - | 0.1 | 0.4 |
| Gr11 | 0.08 | 0.18 | 0.03 | 0.15 | 0.2 | - | - | 0.12~0.25 | - | - | 0.1 | 0.4 |
| Gr12 | 0.08 | 0.25 | 0.03 | 0.15 | 0.3 | - | - | - | 0.6~0.9 | 0.2~0.4 | 0.1 | 0.4 |
| Gr16 | 0.08 | 0.25 | 0.03 | 0.15 | 0.3 | - | - | 0.04~0.08 | - | - | 0.1 | 0.4 |
| Gr23 | 0.08 | 0.13 | 0.03 | 0.15 | 0.25 | 5.5~6.5 | 3.5~4.5 | - | - | - | 0.1 | 0.1 |
Advantages of Using Titanium Alloy Tube
Enhanced Strength and Stability: Titanium alloy tubes provide superior structural integrity for dental bridges, preventing dislodgement or shifting during use. This ensures the stability and reliability of the dental bridge over time.
Long-Term Durability: Titanium’s resistance to wear and corrosion ensures that the tubes maintain their strength and functionality for an extended period, reducing the need for replacements or repairs.
Improved Patient Comfort: The lightweight nature of titanium alloy tubes ensures that the dental bridge is not only stable but also comfortable for patients. This enhances the overall treatment experience and reduces any discomfort from bulky dental appliances.
Highly Resistant to Fatigue: Titanium tubes are designed to withstand the pressure and forces exerted on them during regular oral activities, such as chewing and talking, without bending or breaking. This makes them highly reliable for long-term dental bridge support.
Customization for Individual Needs: Titanium tubes can be precisely manufactured to meet the specific needs of each patient, ensuring that the dental bridge is perfectly supported, regardless of its size or configuration.
| Grade | TA1 TA2 TA3 TA4 TC4 TA7 GR7 GR9 GR11 |
| Titanium Wire | Diameter: 0.1mm-8.0mm |
| Titanium Tube | Length (4-12m), Width (1-50mm), Diameter (48.3-609.6mm) |
| Titanium Rod | Diameter (5.0-350mm), Length (300-6000mm) |
| Titanium Block | Length (100-1500mm), Width (30-600mm), Height (20-300mm) |
| Titanium Plate | Length (1000-6000mm), Width (1000-2000mm), Height (0.8-60mm) |
| Standard | ASTMB863 ASTMB265 ASTMF67 ASTMF136 ISO5832 GB3632 GJB9581 |
Applications of Titanium Alloy Tube
Titanium alloy tubes are widely used in the following dental bridge applications:
Dental Bridge Frameworks: Titanium tubes are commonly used in the construction of dental bridge frameworks, providing reliable and long-lasting support for the entire structure. These tubes ensure the bridge remains securely in place, offering stability and comfort for the patient.
Bridge Retention: Titanium tubes are also used in retention systems for dental bridges, where they help maintain the position of the bridge and prevent any shifting. This is particularly important for bridges that replace missing teeth, ensuring they stay securely in place over time.
Full Mouth Restorations: For patients undergoing extensive dental restorations, titanium alloy tubes are used in multi-unit bridges or full-mouth restorations, where they provide strength and durability for large-scale dental work.
Temporary Bridge Support: In some cases, titanium alloy tubes are used in temporary bridge applications, providing stability and support during the transition period while a permanent bridge is being created.
ABOUT US
Victory Alloy Co., Ltd. is a professional manufacturer specializing in medical alloy materials, with a dedicated focus on the research, development and production of high-performance biomedical alloys.
Our primary product range includes medical-grade titanium alloys, Nitinol (nickel-titanium alloy), cobalt-chromium (CoCr) alloys, platinum-iridium (Pt-Ir) alloys, and medical stainless steel. These high-quality alloys are widely applied in a broad spectrum of medical fields, such as cardiovascular stents, orthopedic implants, interventional guidewires, dental implants, surgical instruments, and disposable medical auxiliary devices. Boasting outstanding biocompatibility, strong corrosion resistance and excellent mechanical properties, our products have won consistent praise from customers across the board.

Client Visits
We welcome client visits to showcase our manufacturing and testing processes. Clients can explore our facility, discuss specific needs, and learn about our quality control methods. Our team ensures a personalized experience to meet your exact requirements for medical applications.

Our Factory

Quality Testing of the Product
Our product undergoes strict testing for tensile strength, corrosion resistance, and biocompatibility to ensure reliable performance in joint implants. We use advanced methods to verify its safety and durability, and all products meet international medical standards for consistent, long-term use in the body.


FAQ
Who is your company?
We are a leading supplier of high-quality medical alloys, specializing in providing durable, biocompatible materials for orthopedic joint replacements and other medical applications.How can I contact your company?
Phone: +86 132 1868 0935
Whatsapp: +86 13218680935
Email: victory@dlx-alloy.com
Can titanium tubes be customized for different dental bridge designs?
Yes, our titanium alloy tubes can be precisely customized to fit the specific design and size requirements of any dental bridge, ensuring the best fit and optimal support for each case.How do titanium tubes compare to other materials used for dental bridge support?
Titanium tubes are superior in terms of strength, durability, and corrosion resistance compared to other materials like stainless steel or gold. They offer long-lasting stability and comfort, making them an ideal choice for dental bridge support.Are titanium tubes safe for use in dental applications?
Yes, titanium is highly biocompatible, meaning it integrates seamlessly with human tissues without causing any allergic reactions or irritation. This makes it a safe and reliable material for dental applications.Do you offer international shipping for titanium tubes?
Yes, we provide international shipping, ensuring that dental professionals worldwide have access to our high-quality titanium alloy tubes for dental bridge support.
