Introduction of Titanium Alloy Tube
Titanium tubes are quickly becoming one of the most innovative materials in dental implants and restoration techniques, offering superior strength, biocompatibility, and long-lasting performance. As dental technology continues to advance, titanium alloy tubes provide a revolutionary solution for enhancing dental care, improving the success rate of implants, and ensuring optimal patient outcomes.
The use of titanium in dental implants has been well-documented, but now, titanium tubes are being integrated into a wider array of dental procedures, including implant-supported bridges, crowns, and restorations. Their versatility and outstanding properties make them ideal for creating customized dental solutions, ensuring a perfect fit and long-term stability for patients.
| China | Classification | UK | Russia | Japan |
| TA1 | Commercial Pure Titanium | GR1 | BT1-00 | TP270 |
| TA2 | Commercial Pure Titanium | GR2 | BT1-0 | TP340 |
| TA3 | Commercial Pure Titanium | GR3 | TP450 | |
| TA4 | Commercial Pure Titanium | GR4 | TP550 | |
TC4 | Ti-6AI-4V | GR5 | BT6 | TAP6400 |
| TA7 | GR6 | |||
| TA9 | Ti-0.2Pd | GR7 | TP340Pb | |
TA18 | Ti-3Al-2.5V | GR9 | 0T4-1B | TAP3250 |
| TA9-1 | GR11 | |||
| TA10 | Ti-0.3Mo-0.8Ni | GR12 | ||
| TB5 | Ti-15V-3Al-3Gr-3Sn | Ti-15333 | ||
| TC4ELI | Ti-6AI-4VELI | GR23 |
Features of Titanium Alloy Tube
Biocompatibility: Titanium tubes are incredibly biocompatible, meaning they integrate well with human bone and tissue. This minimizes the risk of complications, such as rejection or infection, which is critical in dental implant and restoration procedures.
Corrosion Resistance: Titanium’s resistance to corrosion ensures that titanium tubes maintain their structural integrity, even in the moist and acidic environment of the mouth. This makes them highly durable for long-term dental applications.
Lightweight and Strong: Despite their strength, titanium tubes are lightweight, offering a comfortable solution for patients. They provide robust support for dental implants without adding excessive bulk or discomfort.
Customizable Design: Titanium alloy tubes can be customized to meet the specific requirements of individual patients. Whether for temporary or permanent restorations, these tubes can be fabricated to ensure a perfect fit, ensuring better outcomes.
Enhanced Durability: Titanium tubes exhibit exceptional wear resistance, meaning they can withstand the constant pressures of biting, chewing, and talking. This makes them ideal for long-lasting dental restorations that maintain their integrity over time.
| Mechanical Properties | |||||||
| Grade | Condition | Tensile Strength | Yield Strength | Elongation | Reductionof Area | ||
| Ksi | Mpa | Ksi | Mpa | % | |||
| ≥ | |||||||
GR1 | Annealed | 35 | 240 | 25 | 170 | 24 | 30 |
| GR2 | 50 | 345 | 40 | 275 | 20 | 30 | |
| GR3 | 65 | 450 | 55 | 380 | 18 | 30 | |
| GR4 | 80 | 550 | 70 | 483 | 15 | 25 | |
| GR5 | 130 | 895 | 120 | 828 | 10 | 25 | |
| GR6 | 120 | 828 | 115 | 483 | 15 | 25 | |
| GR7 | 50 | 345 | 40 | 275 | 20 | 30 | |
| GR9 | 90 | 620 | 70 | 483 | 15 | 25 | |
| GR11 | 35 | 240 | 25 | 170 | 24 | 30 | |
| GR12 | 70 | 483 | 50 | 345 | 18 | 25 | |
| GR23(Ti-6AL-4VELI) | 125 | 860 | 115 | 795 | 10 | 25 | |
Titanium Alloy Grade Composition Table
| Grade | C ≤ | O ≤ | N ≤ | H ≤ | Fe ≤ | Al | V | Pd | Ni | Mo | Average of Other Elements | Total of Other Elements |
| Gr1 | 0.08 | 0.18 | 0.03 | 0.015 | 0.2 | - | - | - | - | - | 0.1 | 0.4 |
| Gr2 | 0.08 | 0.25 | 0.03 | 0.015 | 0.3 | - | - | - | - | - | 0.1 | 0.4 |
| Gr4 | 0.08 | 0.25 | 0.03 | 0.015 | 0.3 | - | - | - | - | 0.1 | 0.4 | |
| Gr5 | 0.08 | 0.2 | 0.05 | 0.015 | 0.4 | 5.5~6.75 | 3.5~4.5 | - | - | - | 0.1 | 0.4 |
| Gr7 | 0.08 | 0.25 | 0.03 | 0.015 | 0.3 | - | - | 0.12~0.25 | 0.12~0.25 | - | 0.1 | 0.4 |
| Gr9 | 0.08 | 0.15 | 0.03 | 0.015 | 0.25 | 2.5~3.5 | 2.0~3.0 | - | - | - | 0.1 | 0.4 |
| Gr11 | 0.08 | 0.18 | 0.03 | 0.15 | 0.2 | - | - | 0.12~0.25 | - | - | 0.1 | 0.4 |
| Gr12 | 0.08 | 0.25 | 0.03 | 0.15 | 0.3 | - | - | - | 0.6~0.9 | 0.2~0.4 | 0.1 | 0.4 |
| Gr16 | 0.08 | 0.25 | 0.03 | 0.15 | 0.3 | - | - | 0.04~0.08 | - | - | 0.1 | 0.4 |
| Gr23 | 0.08 | 0.13 | 0.03 | 0.15 | 0.25 | 5.5~6.5 | 3.5~4.5 | - | - | - | 0.1 | 0.1 |
Advantages of Using Titanium Alloy Tube
Long-Term Stability and Reliability: Titanium alloy tubes are designed to offer long-lasting support for dental implants, ensuring that they stay secure even under the repeated forces of chewing and speaking. Their high tensile strength and durability reduce the risk of implant failure.
Improved Treatment Outcomes: The integration of titanium tubes into dental implants and restorations ensures better long-term stability. Their biocompatibility helps the implants fuse with the bone, creating a solid foundation for bridges, crowns, and other restorations.
Comfort and Precision: Titanium alloy tubes are lightweight, which helps make dental implants more comfortable for patients. Additionally, their precision manufacturing allows for a highly customized fit, improving both function and aesthetics in dental restorations.
Versatility for Various Applications: Titanium tubes are highly versatile, offering solutions for a wide range of dental procedures, from single tooth implants to full-mouth restorations. Their adaptability makes them an essential part of modern dental care.
Reduced Risk of Complications: The corrosion resistance and biocompatibility of titanium alloy tubes help reduce the risk of complications like gum irritation, infections, or implant failure, which can sometimes occur with other materials.
| Grade | TA1 TA2 TA3 TA4 TC4 TA7 GR7 GR9 GR11 |
| Titanium Wire | Diameter: 0.1mm-8.0mm |
| Titanium Tube | Length (4-12m), Width (1-50mm), Diameter (48.3-609.6mm) |
| Titanium Rod | Diameter (5.0-350mm), Length (300-6000mm) |
| Titanium Block | Length (100-1500mm), Width (30-600mm), Height (20-300mm) |
| Titanium Plate | Length (1000-6000mm), Width (1000-2000mm), Height (0.8-60mm) |
| Standard | ASTMB863 ASTMB265 ASTMF67 ASTMF136 ISO5832 GB3632 GJB9581 |
Applications of Titanium Alloy Tube
Titanium alloy tubes are transforming dental implant and restoration techniques, offering a variety of uses in modern dental care:
Dental Implants: Titanium tubes are often used as part of the core structure for dental implants, providing reliable, long-term support. Their strength allows for secure placement in the jaw, while their biocompatibility ensures successful integration with bone tissue.
Dental Bridges: Titanium tubes are used in the construction of implant-supported dental bridges, providing the strength and stability needed to replace missing teeth. This allows for more secure and functional bridges that can last for many years.
Crown and Abutment Support: Titanium tubes are frequently employed in crown and abutment systems, ensuring a firm and stable connection between the dental implant and the artificial tooth or crown. This enhances the durability of the restoration and improves patient satisfaction.
Temporary Restorations: For patients waiting for permanent dental solutions, titanium tubes can also be used in temporary restorations, providing an effective solution that offers strength and durability while the permanent implant is being created.
Full-Mouth Restorations: Titanium alloy tubes are also used in full-mouth restoration cases, where they provide robust support for multiple implants, ensuring that the final restoration remains stable and functional throughout the patient's daily life.
ABOUT US
Victory Alloy Co., Ltd. is a professional manufacturer specializing in medical alloy materials, with a dedicated focus on the research, development and production of high-performance biomedical alloys.
Our primary product range includes medical-grade titanium alloys, Nitinol (nickel-titanium alloy), cobalt-chromium (CoCr) alloys, platinum-iridium (Pt-Ir) alloys, and medical stainless steel. These high-quality alloys are widely applied in a broad spectrum of medical fields, such as cardiovascular stents, orthopedic implants, interventional guidewires, dental implants, surgical instruments, and disposable medical auxiliary devices. Boasting outstanding biocompatibility, strong corrosion resistance and excellent mechanical properties, our products have won consistent praise from customers across the board.

Client Visits
We welcome client visits to showcase our manufacturing and testing processes. Clients can explore our facility, discuss specific needs, and learn about our quality control methods. Our team ensures a personalized experience to meet your exact requirements for medical applications.

Our Factory

Quality Testing of the Product
Our product undergoes strict testing for tensile strength, corrosion resistance, and biocompatibility to ensure reliable performance in joint implants. We use advanced methods to verify its safety and durability, and all products meet international medical standards for consistent, long-term use in the body.


FAQ
Who is your company?
We are a leading supplier of high-quality medical alloys, specializing in providing durable, biocompatible materials for orthopedic joint replacements and other medical applications.How can I contact your company?
Phone: +86 132 1868 0935
Whatsapp: +86 13218680935
Email: victory@dlx-alloy.com
How do titanium tubes enhance the performance of dental implants?
Titanium tubes enhance dental implants by providing a stable, long-lasting foundation that integrates well with the bone. Their corrosion resistance and strength ensure the implants remain secure and functional, even under the daily pressures of chewing and speaking.Can titanium tubes be used for both temporary and permanent restorations?
Yes, titanium tubes are versatile enough for both temporary restorations and permanent implants. Their strength and customization options make them ideal for various dental applications.Are titanium tubes safe for use in dental applications?
Absolutely. Titanium is one of the safest materials used in dental care, with excellent biocompatibility that reduces the risk of allergic reactions and ensures long-term success in dental implants and restorations.Do titanium tubes offer better longevity than other materials?
Yes, titanium tubes offer superior longevity compared to other materials, thanks to their corrosion resistance and exceptional durability. They can withstand the wear and tear of chewing and biting, making them ideal for long-term use in dental implants and restorations.
