Product Details
Place of Origin: China
Brand Name: Victory
Certification: CE,ROHS,ISO 9001
Model Number: Rtd Pt100
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 50 kilograms
Price: Negotiable
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Product Name: |
Thermocouple Head |
Certificate: |
ISO9001 |
Grade: |
Type K N E |
Protection Tube Entry: |
PF1/2", PF3/4", NPT3/4", BSP1/2", BSP3/4", M20X1.5 |
Material: |
ACD12 Aluminium, SS304, SS316 |
Material Of Terminal Block: |
Ceramic Or Bakelite |
Form Of Terminal Block: |
2 Poles, 3 Poles, 4 Poles, 6 Poles |
Color: |
Silvery |
Application: |
Temperature Sensor |
Weight: |
275G |
Product Name: |
Thermocouple Head |
Certificate: |
ISO9001 |
Grade: |
Type K N E |
Protection Tube Entry: |
PF1/2", PF3/4", NPT3/4", BSP1/2", BSP3/4", M20X1.5 |
Material: |
ACD12 Aluminium, SS304, SS316 |
Material Of Terminal Block: |
Ceramic Or Bakelite |
Form Of Terminal Block: |
2 Poles, 3 Poles, 4 Poles, 6 Poles |
Color: |
Silvery |
Application: |
Temperature Sensor |
Weight: |
275G |
Thermocouple Head KNE KSE Used For Thermocouple Sensor
Thermocouple heads are available in a variety of materials and NPT process thread sizes. We stock metal heads in Aluminum, Cast Iron, Stainless Steel, Brass, and Nickel Plated Steel. We also stock plastic heads in Polypropylene, Delrin, and Nylon.
The thermocouple head is an important part of the construction of an accurate thermocouple system. The head is used to house the thermocouple terminal block. The block also connects the thermocouple element to the extension wire. The heads function is two fold. To protect the connections from the elements. It also maintains a constant temperature around the connections.
Parameter
| Product Name | Chinese Code | International Type | Sheath material | Outer dia.(mm) | Temperature /℃ |
| Ni Cr - Ni Si | KK | K | SS304 | 0.5-1.0 | 400 |
| SS321 | 1.5-3.2 | 600 | |||
| SS316 | 4.0-8.0 | 800 | |||
| SS310 | 0.5-1.0 | 500 | |||
| SS310 | 1.5-3.2 | 800 | |||
| INCL600 | 4.0-6.4 | 900 | |||
| INCL600 | 8.0-12.7 | 1000 | |||
| Ni Cr Si - Ni Si | KN | N | SS304 | 0.5-1.0 | 400 |
| SS321 | 1.5-3.2 | 600 | |||
| SS316 | 4.0-8.0 | 800 | |||
| SS310 | 0.5-1.0 | 500 | |||
| SS310 | 1.5-3.2 | 800 | |||
| INCL600 | 4.0-6.4 | 900 | |||
| INCL600 | 8.0-12.7 | 1000 | |||
| Ni Cr- Constantan | KE | E | SS304 | 0.5-1.0 | 400 |
| SS321 | 1.5-3.2 | 500 | |||
| SS316 | 4.0-8.0 | 800 | |||
| Fe - Constantan | KJ | J | SS304 | 1.0 | 300 |
| SS321 | 1.5-3.2 | 500 | |||
| SS316 | 4.0-8.0 | 800 | |||
| Cu - Constantan | KT | T | SS304 | 1.0 | -200-100 |
| SS321 | 1.5-3.2 | 100-200 | |||
| SS316 | 4.0-8.0 | 100-350 |
|
|
