Product Details
Place of Origin: China
Brand Name: Victory
Certification: CE,ROHS,ISO 9001
Model Number: ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-7,ERNiCr-3
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 15
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Material: |
Ni, Mo, Cr |
Elongation: |
≥22 % |
Density: |
8.60 G/cm3 |
Tensile Strength Rm N/mm²: |
≥600 |
Yieldstrength R P0. 2 N/mm²: |
≥360 |
Melting Point: |
1310-1360℃ |
Certificates: |
AWS A5.14 / ASME SFA A5.14 |
Material: |
Ni, Mo, Cr |
Elongation: |
≥22 % |
Density: |
8.60 G/cm3 |
Tensile Strength Rm N/mm²: |
≥600 |
Yieldstrength R P0. 2 N/mm²: |
≥360 |
Melting Point: |
1310-1360℃ |
Certificates: |
AWS A5.14 / ASME SFA A5.14 |
ASME SFA A5.14 ERNiCrMo 13 1.6mm Nickel Welding Wire
ERNiCr-3 nickel alloy bare wire is used for GMAW, GTAW, and SAW Nickel Alloy welding.It is used for joining base materials such as UNS number N06600. This includes ASTM grades B163, B166, B167, and B168. This alloy can also be used for dissimilar welding using various nickel alloys to stainless steels or carbon steels, as well as for overlaying carbon steels. Also used for welding 9% nickel steels to one another having high impact strength at low temperatures. This versatile alloy has high strength and good corrosion resistance, with oxidation resistance and creeprupture strength at elevated temperatures.
Nickel Based Welding Wire
Nickel alloy welding wire ERNiCrMo-13 is a nickel-chromium-molybdenum alloy with extra low carbon and silicon contents. It offers excellent corrosion resistance, high mechanical strength, and better thermal stability. Because of its low silicon and carbon contents and no tungsten, Pinnacle Alloys ERNiCrMo-13 is not prone to grain-boundary precipitation during hot forming and welding. Pinnacle Alloys ERNiCrMo-13 is well suited for welding in a wide variety of chemical processing facilities in both oxidizing and reducing media. This wire provides exceptional weldability and very low sensitivity to hot cracking.
It is designed to match the nickel base alloy commonly known as alloy 59. The high level of Mo is similar to alloys C276 but performance in a wide range of more oxidising media is significantly enhanced in alloy 59 by increasing Cr to 23%. This alloy also provides a tough Nb-free weld metal for dissimilar welds in superaustenitic and superduplex stainless steel or combinations of these with Ni base alloys.
Nickel alloy Weling wire series:
ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-3,ERNiCrFe-7,ERNiCr-3,ERNiCr-7,ERNiCu-7,ERNi-1, ER70S-6.
Standard: Conforms to Certification AWS A5.14 ASME SFA A5.14
Size: 0.8MM / 1.0MM / 1.2MM / 1.6MM / 2.4MM / 3.2MM / 3.8MM / 4.0MM / 5.0MM
Form: MIG(15kgs/spool), TIG(5kgs/box),Strip
Nickel welding wire Nickel welding wire Nickel welding wire Nickel welding wire Nickel welding wire
| CHEMICAL COMPOSITION % | |||||||||||
| C | P | S | Mn | Fe | Si | Ni+Co | Ti | Nb+Ta | Cr | Cu | Others |
| ≤0.1 | ≤0.03 | ≤0.015 | 2.5-3.5 | ≤3.0 | ≤0.5 | ≥67 | ≤0.75 | 3.15-4.15 | 18-22 |
≤0.50
|
|
| Ultimate tensile strength (psi) | 80,000 |
| Yield strength (0.2% offset) (psi) | 40,000 |
| Elongation in 2" (%) | 30 |
| Typical Welding Parameters | |||||
| Diameter | Process | Volt | Amps (flat) | Amps (V/OH) | |
| inch | (mm) | ||||
| 0.035 | 0.9 | GMAW | 26-29 | 150-190 | Spray Transfer 100% Argon |
| 0.045 | 1.2 | GMAW | 28-32 | 180-220 | Spray Transfer 100% Argon |
| 1/16 | 1.6 | GMAW | 29-33 | 200-250 | Spray Transfer 100% Argon |
| 1/16 | 1.6 | GTAW | 14-18 | 90-130 | 100% Argon |
| 3/32 | 2.4 | GTAW | 15-20 | 120-175 | 100% Argon |
| 1/8 | 3.17 | GTAW | 15-20 | 150-220 | 100% Argon |
