Changzhou Victory Technology Co., Ltd victory@dlx-alloy.com 86-199-06119641
Product Details
Place of Origin: China
Brand Name: Victory
Certification: CE,ROHS,ISO 9001
Model Number: 45CT
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 5 Kg
Price: Negotiable
Packaging Details: Spool package with Carton box, Coil package with polybag
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Product Name: |
Thermal Spray Wire |
Grade: |
45CT |
Material: |
Tungsten |
Bonding Strength: |
48.26 N/mm2 |
Deposit Rate: |
10 Lbs/hr/100A |
Coating Hardness: |
HRC 30-35 |
Product Name: |
Thermal Spray Wire |
Grade: |
45CT |
Material: |
Tungsten |
Bonding Strength: |
48.26 N/mm2 |
Deposit Rate: |
10 Lbs/hr/100A |
Coating Hardness: |
HRC 30-35 |
Introduction:
NiCrTi/45CT wire is a Nickel/Chrome/Titanium wire developed specifically for boiler applications. This second generation material replaces 06BXP and produces coatings which are extremely resistant to corrosive vanadium and sulfur gases in boiler atmospheres.
Typical Uses and Applications:
This material has proven very effective in providing long term protection to boiler tubes against high temperature sulfidation. The wrought material is highly resistant to sulfur/vanadium atmospheres up to 1800°F. Wrought material of this type has shown a 2 mil per year corrosion rate over a nine year period when used in the super heater section of boilers. Coatings of 45CT wire applied to boiler tubes have shown virtually no loss of thickness or spalling after 24 months of service (as of this writing).
Thermal spray wire
| Item | Inconel 625 | Ni95Al5 | 45CT | Monel 400 | HC-276 | Cr20Ni80 | K500 |
| C | ≤0.05 | ≤0.02 | 0.01-0.1 | ≤0.04 | ≤0.02 | ≤0.08 | ≤0.25 |
| Mn | ≤0.4 | ≤0.2 | ≤0.2 | 2.5-3.5 | ≤1.0 | ≤0.06 | ≤1.5 |
| P | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.02 | ≤0.01 |
| S | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 |
| Si | ≤0.15 | ≤0.2 | ≤0.2 | ≤0.15 | ≤0.08 | 0.75-1.6 | ≤0.5 |
| Cr | 21.5-23 | ≤0.2 | 42-46 | - | 14.5-16 | 20-23 | - |
| Ni | Rest | Rest | Rest | 65-67 | Rest | Rest | Rest |
| Cu | - | - | - | Rest | - | - | 27-33 |
| Mo | 8.5-10 | - | - | - | 15-17 | - | - |
| Ti | ≤0.4 | 0.4-1 | 0.3-1.0 | 2.0-3.0 | - | - | 0.35-0.85 |
| Al | ≤0.4 | 4--5 | - | ≤0.5 | - | - | 2.3-3.15 |
| Fe | ≤1.0 | - | ≤0.5 | ≤1.0 | 4.0-7.0 | - | ≤1.0 |
| Nb | 3.5-4.15 | - | - | - | - | ≤1.0 | - |
| Co | - | - | - | - | - | - | - |
| V | - | - | - | - | ≤0.35 | - | - |
| W | - | - | - | - | 3.0-4.5 | - | - |
| Impurities | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.50 |
Feature:
Application:
Size range Wire: 0.12 to 8.0 mm.
|
|
Q&A:
What are the main advantages of 45CT thermal spray wire?
The main advantages of 45CT thermal spray wire include higher strength and hardness, wear resistance, and corrosion resistance (depending on the specific alloy composition).
What is the difference between 45CT thermal spray wire and other spray materials?
Compared with other spray materials, 45CT thermal spray wire is a type of carbon steel with good strength and wear resistance, and is suitable for some applications requiring strength and hardness.
What is the spraying process of 45CT thermal spray wire?
45CT thermal spray wire usually uses gas thermal spray technology, such as flame spraying or plasma spraying. These technologies spray a thermal spray filament onto a base material to form a coating.
