Product Details
Place of Origin: China
Brand Name: Victory
Certification: CE
Model Number: Cr10Ni90
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag for Resistance wire
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Material: |
Nickel, Chromium |
Nickel(Min): |
89% |
Tensile Strength: |
637MPA |
Magnetic Permeability: |
0.78+/-0.05 |
Elongtation: |
≥20% |
Application: |
Heating, Resistivity |
Condition: |
Hard / Soft |
Sureface: |
Bright, Oxided, Acide |
Delivery Time: |
7-20 Days |
Name: |
NiCr Alloy Wire |
Material: |
Nickel, Chromium |
Nickel(Min): |
89% |
Tensile Strength: |
637MPA |
Magnetic Permeability: |
0.78+/-0.05 |
Elongtation: |
≥20% |
Application: |
Heating, Resistivity |
Condition: |
Hard / Soft |
Sureface: |
Bright, Oxided, Acide |
Delivery Time: |
7-20 Days |
Name: |
NiCr Alloy Wire |
Introduction:
Cr10Ni90 alloy wire is a high-quality nickel-based alloy wire, mainly composed of 10% chromium and 90% nickel. This alloy wire has excellent high temperature stability and oxidation resistance, making it suitable for a variety of high temperature applications. Due to its low resistivity, Cr10Ni90 alloy wire is widely used in electric heating devices and heating elements.
At the same time, the alloy wire also has good corrosion resistance and can resist the erosion of acidic and alkaline media, making it very popular in fields such as the chemical industry and petroleum industry.
Characteristic:
1. Oxidation resistance: Cr10Ni90 alloy wire has good antioxidant properties and can resist oxidation and burning damage in high temperature environments, extending its service life.
2. Thermoelectric properties: As the temperature-sensitive part of the thermocouple, Cr10Ni90 alloy wire can generate a relatively large thermoelectric potential difference, is sensitive to temperature changes, and has high measurement accuracy and stability.
3. Processing performance: Cr10Ni90 alloy wire has good processability and can be formed and processed by drawing, cold drawing, welding, etc.
Technical Parameters:
| Performance material | Cr10Ni90 | Cr20Ni80 | Cr30Ni70 | Cr15Ni60 | Cr20Ni35 | Cr20Ni30 | |
| Composición | Ni | 90 | Rest | Rest | 55.0～61.0 | 34.0～37.0 | 30.0～34.0 |
| Cr | 10 | 20.0～23.0 | 28.0～31.0 | 15.0～18.0 | 18.0～21.0 | 18.0～21.0 | |
| Fe | － | ≤1.0 | ≤1.0 | Rest | Rest | Rest | |
| Temperatura máxima℃ | 1300 | 1200 | 1250 | 1150 | 1100 | 1100 | |
| Punto de fusion ℃ | 1400 | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Densidad g/cm3 | 8.7 | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 | |
| Resistividad μΩ·m,20℃ | 0.76±0.05 | 1.09±0.05 | 1.18±0.05 | 1.12±0.05 | 1.00±0.05 | 1.04±0.05 | |
| Alargamiento a la ruptura | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 | |
| Calor especifico J/g.℃ | － | 0.44 | 0.461 | 0.494 | 0.5 | 0.5 | |
| Conductividad térmica KJ/m.h℃ | － | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
| Coeficiente de expansión de líneas a×10-6/(20～1000℃) | － | 18 | 17 | 17 | 19 | 19 | |
| Estructura micrográfica | － | Austenite | Austenite | Austenite | Austenite | Austenite | |
| Propiedades magnéticas | － | Nonmagnetic | Nonmagnetic | Nonmagnetic | Weak magnetic | Weak magnetic | |
| Form | Specification | |
| Wire | Diameter=0.025mm~8mm | |
| Flat wire | Width=0.40~6.0mm | Thick=0.03~0.50mm |
| Strip | width=8~250mm | Thick=0.05~3.0mm |
| Bar | Diameter=8~100mm | Long=50~1000 |
Service:
Safety is our utmost priority when it comes to our NiCr alloy heaters. We have implemented multiple safety measures, including overload protection and overheating protection, to ensure the safe and reliable operation of our heaters. You can have peace of mind knowing that our products prioritize your safety and provide a secure heating solution.
|
|
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Size dimension range:
Wire: 0.01-10mm
Ribbons: 0.05*0.2-2.0*6.0mm
Strip: 0.05*5.0-5.0*250mm
NiCr series: Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30
Packing and Shipping:
Sturdy cardboard boxes are used for packaging NiCr Alloy.
Each box has dimensions of approximately 26 cm (length) x 26 cm (width) x 30 cm (height).
The shipping method for NiCr Alloy depends on the customer's requirements.
FAQ :
What is the conductivity of Cr10Ni90 alloy wire?
Cr10Ni90 alloy wire has good electrical conductivity and can effectively convert electrical energy into thermal energy.
What is the corrosion resistance of Cr10Ni90 alloy wire?
Cr10Ni90 alloy wire has good corrosion resistance in general industrial environments and can resist the erosion of most chemical media and corrosives.
Do you provide samples of Cr10Ni90 alloy wire?
Yes, we can provide samples of Cr10Ni90 alloy wire for customers to test and evaluate.
