Product Details
Place of Origin: China
Brand Name: Victory
Model Number: Ni200 Ni201
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 5 Kg
Price: 5 - 99 kilograms US$45.00
Packaging Details: Plastic film or waterproof woven bag inside, wire packed in spool put into carton,coil wire or strip wire put into wooden case
Delivery Time: 7 to 20 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Standard: |
ASTM B164, DIN 17752, JIS NW2200 |
Grade Type: |
N4, N6, Ni200, Ni201 |
Material: |
Ni |
Ni(min): |
99% |
Melting Point: |
1435-1446°C |
Elongation (≥ %): |
35% |
Shape: |
Wire |
Ultimate Strength (≥ MPa): |
462 |
Application: |
Battery Pack, Electric Apparatus,Computers |
Size: |
0.025-10mm, Can Customized |
Technique: |
Cold Rolled,bending,cutting,decoiling |
Density(g/cm3): |
8.9 |
Surface: |
Bright |
Advantage: |
Corrosion-resistant,Good Strength |
Other Form: |
Strip, Ribbon, Bar, Tube, Plate |
Standard: |
ASTM B164, DIN 17752, JIS NW2200 |
Grade Type: |
N4, N6, Ni200, Ni201 |
Material: |
Ni |
Ni(min): |
99% |
Melting Point: |
1435-1446°C |
Elongation (≥ %): |
35% |
Shape: |
Wire |
Ultimate Strength (≥ MPa): |
462 |
Application: |
Battery Pack, Electric Apparatus,Computers |
Size: |
0.025-10mm, Can Customized |
Technique: |
Cold Rolled,bending,cutting,decoiling |
Density(g/cm3): |
8.9 |
Surface: |
Bright |
Advantage: |
Corrosion-resistant,Good Strength |
Other Form: |
Strip, Ribbon, Bar, Tube, Plate |
Physical properties: Pure nickel wire has good ductility and plasticity and can be easily drawn into filaments. Its diameter can be very small, ranging from a few microns to a few millimeters.
Chemical properties: Pure nickel wire has good corrosion resistance to most common chemicals. It has good stability to water, air and most acids at room temperature. However, under high temperature and strong oxidizing conditions, pure nickel wire may undergo oxidation reactions.
Thermal properties: Pure nickel wire has a high melting point (about 1455 degrees Celsius) and a low linear expansion coefficient. This makes pure nickel wire have good stability and heat resistance in high temperature environments.
Application areas: Pure nickel wire is widely used in many fields. It is often used as a material for resistance wires, heating wires and heating elements. Pure nickel wire is also widely used in the chemical industry, electronics industry, aerospace and medical fields.
| Specifications | Values |
|---|---|
| Product name | Pure Nickel Wire |
| Ni(min) | 99% |
| Grade | N4,N6,Ni200,Ni201 |
| Size | 0.025-10mm |
| Shape | Wire |
| Hardness | S,1/4H,1/2H,3/4H,H |
| Melting Point | 1435-1446°C |
| Elongation (≥ %) | 35% |
| Resistance (μΩ.m) | 15 |
| Application | Industry,Electronic |
1. Resistance wire and electric heating elements: Pure nickel wire has high resistivity and good high temperature resistance, and is often used to manufacture resistance wire and electric heating elements, such as electric furnace heaters, heaters, electric heating wires, etc.
2. Electronic components: Pure nickel wire is widely used in the manufacture of electronic components, such as electronic parts, resistors, inductors, capacitors, wires, etc. Its high temperature stability and good electrical conductivity make it an important material in the electronics industry.
3. Wires and connectors: Pure nickel wire is used as conductor material for wires and cables, especially suitable for high temperature environments and situations with high corrosion resistance requirements. They are also widely used in electrical connection components such as connectors, sockets and insulators.
4. Precision instruments: Because pure nickel wire has excellent mechanical properties and corrosion resistance, it is widely used in the process of manufacturing precision instruments and meters. For example, pure nickel wire is used to make thermometers, pressure gauges, flow meters, optical instruments, etc.
5. Chemical industry: Pure nickel wire is used in the chemical industry to manufacture reactors, distillation equipment, catalysts and storage tanks, etc. Due to its good corrosion resistance, pure nickel wire can withstand the erosion of a variety of acidic and alkaline media.
6. Medical devices: Pure nickel wire is widely used in the field of medical devices, such as making surgical instruments, artificial joints, dental instruments, etc. Its biocompatibility and corrosion resistance make it one of the ideal materials in the medical field.
Our Nickel Wire is packaged and shipped with utmost care to ensure its safe and secure delivery to our customers.
Packaging:
We offer various shipping options for our customers to choose from:
At Nickel Wire, we strive to provide the best packaging and shipping services to ensure our customers receive their products in pristine condition and on time.
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
|
|
Is pure nickel wire made of pure nickel material?
Pure nickel wire is made of high-purity nickel material, usually with a nickel content of more than 99.5%.
Can pure nickel wire be customized as needed?
Yes, manufacturers can customize pure nickel wire according to customer needs and specifications, including diameter, length, chemical composition and surface treatment, etc.
What is the linear expansion coefficient of pure nickel wire?
The linear expansion coefficient of pure nickel wire is about 13.3×10^-6/°C, which has low thermal expansion performance.
