Product Details
Place of Origin: China
Brand Name: Victory
Model Number: Ni200 Ni201
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 5 Kg
Price: 5 - 99 kilograms US$45.00
Packaging Details: Plastic film or waterproof woven bag inside, wire packed in spool put into carton,coil wire or strip wire put into wooden case
Delivery Time: 7 to 20 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Standard: |
ASTM B164, DIN 17752, JIS NW2200 |
Grade Type: |
N4, N6, Ni200, Ni201 |
Material: |
Ni |
Ni(min): |
99% |
Melting Point: |
1435-1446°C |
Elongation (≥ %): |
35% |
Shape: |
Wire |
Ultimate Strength (≥ MPa): |
462 |
Application: |
Battery Pack, Electric Apparatus,Computers |
Size: |
0.025-10mm, Can Customized |
Technique: |
Cold Rolled,bending,cutting,decoiling |
Density(g/cm3): |
8.9 |
Surface: |
Bright |
Advantage: |
Corrosion-resistant,Good Strength |
Other Form: |
Strip, Ribbon, Bar, Tube, Plate |
Standard: |
ASTM B164, DIN 17752, JIS NW2200 |
Grade Type: |
N4, N6, Ni200, Ni201 |
Material: |
Ni |
Ni(min): |
99% |
Melting Point: |
1435-1446°C |
Elongation (≥ %): |
35% |
Shape: |
Wire |
Ultimate Strength (≥ MPa): |
462 |
Application: |
Battery Pack, Electric Apparatus,Computers |
Size: |
0.025-10mm, Can Customized |
Technique: |
Cold Rolled,bending,cutting,decoiling |
Density(g/cm3): |
8.9 |
Surface: |
Bright |
Advantage: |
Corrosion-resistant,Good Strength |
Other Form: |
Strip, Ribbon, Bar, Tube, Plate |
Under high temperature and strong oxidizing conditions, pure nickel wire will undergo oxidation reactions. The specific oxidation reaction depends on the type of oxidant, temperature and the interaction between the oxidant and pure nickel.
Under common atmospheric conditions, pure nickel wire reacts with oxygen to form nickel oxide (NiO). This oxidation reaction usually occurs at high temperatures, especially to form an oxide layer on the surface of the nickel wire. The thin layer formed by nickel oxide can provide some corrosion resistance and oxidation protection, but under extreme conditions, such as high temperature and the presence of strong oxidants, the nickel oxide layer may thicken further.
When pure nickel wire is exposed to steam or the presence of water, a steam oxidation reaction occurs. This reaction results in the formation of a mixture of nickel hydroxide (Ni(OH)2) and nickel oxide (NiO) on the surface of the nickel wire. This oxide layer is usually gray or green in color and has better corrosion resistance.
In some special oxidizing environments, such as gases containing sulfide or chloride, pure nickel wire may undergo oxidation reactions of sulfide or chloride. These reactions lead to the formation of corresponding sulfide or chloride oxides on the surface of pure nickel wire.
It should be noted that oxidation reactions of pure nickel wire may negatively affect its performance and application. The formation of oxide layers can lead to increased resistance, reduced electrical conductivity, and changes in mechanical properties of the material. Therefore, the interaction of pure nickel wire with oxidants needs to be considered in specific applications, and appropriate protective measures or other materials must be selected to protect the pure nickel wire from the effects of oxidation.
Pure nickel wire has certain characteristics compared with other metals in terms of electrical conductivity. Here are some comparisons to some common metals:
| Specifications | Values |
|---|---|
| Product name | Pure Nickel Wire |
| Ni(min) | 99% |
| Grade | N4,N6,Ni200,Ni201 |
| Size | 0.025-10mm |
| Shape | Wire |
| Hardness | S,1/4H,1/2H,3/4H,H |
| Melting Point | 1435-1446°C |
| Elongation (≥ %) | 35% |
| Resistance (μΩ.m) | 15 |
| Application | Industry,Electronic |
Pure nickel wire has good corrosion resistance, which makes it very valuable in some special applications. Here are some important points about the corrosion resistance of pure nickel wire:
It should be noted that although pure nickel wire has good corrosion resistance, its corrosion resistance may be limited in some special corrosive environments, such as strongly oxidizing acids, fluoride solutions, etc.
Our Nickel Wire is packaged and shipped with utmost care to ensure its safe and secure delivery to our customers.
Packaging:
We offer various shipping options for our customers to choose from:
At Nickel Wire, we strive to provide the best packaging and shipping services to ensure our customers receive their products in pristine condition and on time.
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
|
|
What are the applications of pure nickel wire in the medical field?
Pure nickel wire is commonly used in the medical field to manufacture implantable medical devices, surgical instruments and medical wires, etc. It has biocompatibility and corrosion resistance.
How is pure nickel wire transported?
Pure nickel wire can be transported by land, sea or air transport, the specific choice depends on factors such as distance, speed and safety.
How strong and ductile is pure nickel wire?
Pure nickel wire has high strength and good ductility, and can adapt to various processing and forming requirements.
