Product Details
Place of Origin: China
Brand Name: Victory
Certification: CE
Model Number: Cr20Ni30
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag for Resistance wire
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Max. Continuous Service Temp. Of Element(ºC): |
1100 |
Melting Point: |
1390 |
Resistivity: |
1.04±0.05 |
Density(g/cm3): |
7.9 |
Thermal Conductivity (KJ/m·h·ºC): |
43.8 |
Coefficient Of Lines Expansion(α×10-6/ºC): |
19 |
Melting Point Approx.( ºC): |
1390 |
Elongation At Rupture(%): |
>20 |
Max. Continuous Service Temp. Of Element(ºC): |
1100 |
Melting Point: |
1390 |
Resistivity: |
1.04±0.05 |
Density(g/cm3): |
7.9 |
Thermal Conductivity (KJ/m·h·ºC): |
43.8 |
Coefficient Of Lines Expansion(α×10-6/ºC): |
19 |
Melting Point Approx.( ºC): |
1390 |
Elongation At Rupture(%): |
>20 |
Cr20Ni30 is an exceptional material that offers a range of desirable properties, making it an ideal choice for various applications. It is known for its excellent ductility, workability, and weldability, even under high temperatures and seismic stress. This material is particularly useful in situations where high strength and durability are crucial.
One of the key features of Cr20Ni30 is its high and stable resistance to corrosion. This makes it an excellent choice for applications where the material will be exposed to harsh environments or corrosive substances. Additionally, the material has outstanding surface oxidation resistance, making it suitable for use in high-temperature settings.
Another advantage of Cr20Ni30 is its exceptional coil-forming ability. This property makes it easy to shape and mold the material into various forms and shapes, making it highly versatile and useful in a wide range of applications.
Overall, Cr20Ni30 is a highly desirable material that offers a range of properties that make it an excellent choice for various industrial and commercial applications. Its high strength, durability, and resistance to corrosion and oxidation make it an ideal choice for use in harsh environments, while its excellent coil-forming ability makes it easy to work with and shape to meet specific needs.
| Form | Specification | |
| Wire | Diameter=0.025mm~8mm | |
| Flat wire | Width=0.40~6.0mm | Thick=0.03~0.50mm |
| Strip | width=8~250mm | Thick=0.05~3.0mm |
| Bar | Diameter=8~100mm | Long=50~1000 |
|
|
