Product Details
Place of Origin: China
Brand Name: Victory
Certification: CE,ROHS,ISO 9001
Model Number: Incoloy 825
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 5 Kg
Price: Negotiable
Packaging Details: Plastic film or waterproof woven bag inside, wire packed in spool put into carton,coil wire or strip wire put into wooden case
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Name: |
Incoloy 825 Wire |
Material: |
Ni Fe Cr Mo |
Nickel(Min): |
38-46% |
Application: |
Reactors, Transfer Pipes, Mixers |
Coefficient Of Expansion: |
14.0 μm/m °C (20 – 100°C) |
Modulus Of Rigidity: |
75.9 KN/mm² |
Density (g/m3): |
8.14 G/cm3 |
Modulus Of Elasticity: |
196 KN/mm² |
Elongation (≥ %): |
30% |
Melting Point: |
1400°C |
Tensile Strength: |
550 MPa |
Yield Strength: |
220 MPa |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Name: |
Incoloy 825 Wire |
Material: |
Ni Fe Cr Mo |
Nickel(Min): |
38-46% |
Application: |
Reactors, Transfer Pipes, Mixers |
Coefficient Of Expansion: |
14.0 μm/m °C (20 – 100°C) |
Modulus Of Rigidity: |
75.9 KN/mm² |
Density (g/m3): |
8.14 G/cm3 |
Modulus Of Elasticity: |
196 KN/mm² |
Elongation (≥ %): |
30% |
Melting Point: |
1400°C |
Tensile Strength: |
550 MPa |
Yield Strength: |
220 MPa |
Condition: |
Hard / Soft |
Sureface: |
Bright,Oxided |
Introduction:
Incoloy 825 Wire is an alloy wire composed of elements such as nickel, iron, chromium and molybdenum. This alloy wire is suitable for reactors, conveying pipes, stirrers and other fields.
Key parameters include a nickel content between 38-46% and a density of 8.14 g/cm3. Its linear expansion coefficient is 14.0 μm/m·C (in the range of 20-100 °C), its stiffness modulus is 75.9 kN/mm2, and its elastic modulus is 196 kN/mm2. In addition, the alloy wire has an elongation of more than 30%, a tensile strength of 550 MPa, and a yield strength of 220 MPa.
Incoloy 825 Wire is widely used in reactors, pipelines and stirrers. It has excellent corrosion resistance and high temperature stability, and can withstand chemical reactions and high temperature environment requirements. This alloy wire can be used to manufacture corrosion-resistant equipment and components, ensuring the safety and reliability of operations.
Incoloy 825 Wire is available in two conditions: hard and soft. Surface treatments are available in bright and oxidized finishes to suit different needs.
To sum up, Incoloy 825 Wire is an alloy wire widely used in reactors, transportation pipes, mixers and other fields. With its excellent physical and mechanical properties, as well as corrosion resistance and high temperature stability, it can meet the requirements of various chemical industries and high temperature environments.
Parameter:
|
Chemical Composition (%)
|
|||||||||
|
C
|
Si
|
Mn
|
S
|
Mo
|
Ti
|
Cr
|
Ni
|
Fe
|
Cu
|
|
≤0.05
|
≤0.50
|
≤1.00
|
≤0.03
|
≤2.5~3.5
|
≤0.6~1.2
|
19.5~23.5
|
38.0~46.0
|
≥22.0
|
1.5~3.0
|
|
Standard
|
|||
|
Sheet/Plate
|
Round bar/Wire
|
Pipe
|
Tube
|
|
ASME SB-424
ASME SB-906
|
ASME SB-425
|
ASME SB-423
ASME SB-829
ASME SB-163
ASME SB-751
ASME SB-775
|
ASME SB-704
ASME SB-705 ASME SB-751 ASME SB-775 |
|
Mechanical Properties
|
||||
|
Status
|
Tensile Strength
(Rm N/mm2)
|
Yield strength
(RP0.2N/mm2)
|
Elongation(A5%)
|
HB
|
|
Solution treatment
|
550
|
220
|
30
|
≤200
|
|
Incoloy 825 (NS142) similiaer trademark
|
|||
|
UNS
|
Trademark
|
JIS
|
W.Nr
|
|
N08825
|
Incoloy825
|
NCF825
|
2.4858
|
|
|
Characteristic:
Advantage:
Specific applications:
Other relevant knowledge points:
Equipment Cleaning and Disinfection: In pharmaceutical equipment manufactured with Incoloy 825 alloy wire, proper cleaning and disinfection procedures are critical to ensuring the hygiene and safety of the equipment.
Compliance and standards: During the manufacturing process of pharmaceutical equipment, follow applicable specifications and standards, such as cGMP (Good Manufacturing Practice), etc., to ensure product quality and compliance.
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
|
|
Q & A:
Q: What is the corrosion resistance of Incoloy 825 Wire?
A: Incoloy 825 Wire offers exceptional corrosion resistance in various corrosive environments, including sulfuric acid, phosphoric acid, and seawater.
Q: What industries commonly use Incoloy 825 Wire?
A: Incoloy 825 Wire finds applications in a wide range of industries, including chemical processing, oil and gas, marine, and pollution control.
