Product Details
Place of Origin: China
Brand Name: Victory
Certification: ISO9001 ROHS
Model Number: Inconel 718
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 10 Kg
Price: Negotiable
Packaging Details: Spool Carton box, Coil package with polybag,then in woodencase
Delivery Time: 20~40 Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Name: |
ASTM B637 Haynes 718 Nichrofer 5219 Nickel Alloy Inconel 718 Wire With Tensile 1310-1515mpa |
Material: |
Nickel Chromium Iron |
Ni (Min): |
50~55% |
Density: |
8.24 G/cm3 |
Melting Point: |
1260-1320°C |
Elongation (≥ %): |
25 % |
Thermal Conductivity: |
15.9 W/m·K |
Finishing: |
Bright,Oxided, Acid White |
Application: |
Construction, Industry Oil, Piping Systems |
Yield Strength: |
550MPa |
Tensile Strength: |
910 MPa |
Hardness: |
≤ 363 HB |
Standard: |
ASTM, ASME |
Size: |
6~200mm |
Shape: |
Round, Square, Flat |
Name: |
ASTM B637 Haynes 718 Nichrofer 5219 Nickel Alloy Inconel 718 Wire With Tensile 1310-1515mpa |
Material: |
Nickel Chromium Iron |
Ni (Min): |
50~55% |
Density: |
8.24 G/cm3 |
Melting Point: |
1260-1320°C |
Elongation (≥ %): |
25 % |
Thermal Conductivity: |
15.9 W/m·K |
Finishing: |
Bright,Oxided, Acid White |
Application: |
Construction, Industry Oil, Piping Systems |
Yield Strength: |
550MPa |
Tensile Strength: |
910 MPa |
Hardness: |
≤ 363 HB |
Standard: |
ASTM, ASME |
Size: |
6~200mm |
Shape: |
Round, Square, Flat |
Inconel 718 alloy
Inconel 718 is a high-strength, corrosion-resistant nickel-chromium alloy known for its excellent mechanical properties at elevated temperatures. It is commonly used in aerospace, oil and gas, and other high-stress applications.
What is the difference between Inconel X750 and 718 springs?
nconel X750 and Inconel 718 are both nickel-based superalloys, but they have different compositions and properties that make them suitable for different applications. Here’s a comparison of the two, particularly in the context of spring materials:
1. Composition:
Inconel 718: Contains nickel (50-55%), chromium (17-21%), iron (up to 19%), molybdenum (2.8-3.3%), and niobium (4.75-5.5%). It also has small amounts of other elements like titanium and aluminum.
Inconel X750: Contains nickel (70-75%), chromium (14-17%), iron (5-9%), and significant amounts of titanium (1-2.5%) and aluminum (0.2-0.6%). It is primarily used in high-temperature applications.
2. Mechanical Properties:
Inconel 718: Known for its high strength, excellent fatigue resistance, and good ductility, particularly at elevated temperatures. It can be heat-treated to enhance its properties.
Inconel X750: Offers high strength and oxidation resistance at elevated temperatures, but it has lower ductility compared to Inconel 718. It is often used in applications that require stability under high-temperature conditions.
3. Corrosion Resistance:
Inconel 718: Excellent corrosion resistance, particularly in acidic and saline environments, making it suitable for aerospace and oil and gas applications.
Inconel X750: Also offers good corrosion resistance but is more focused on high-temperature oxidation resistance rather than resistance to acidic environments.
4. Applications:
Inconel 718: Commonly used in aerospace components, gas turbines, and springs that operate in high-stress and corrosive environments.
Inconel X750: Primarily used in gas turbine engines, nuclear reactors, and other high-temperature applications where stability and strength are critical.
5. Heat Treatment:
Inconel 718: Can be age-hardened to improve strength and hardness through specific heat treatment processes.
Inconel X750: Typically used in the solution-annealed condition; aging is less common as it is designed for stability rather than hardening.
Chemical Properties of Inconel 718
Nickel (plus Cobalt) .......................................................50.00-55.00
Chromium......................................................................17.00-21.00
Iron .....................................................................................Balance
Niobium (plus Tantalum)....................................................4.75-5.50
Molybdenum .....................................................................2.80-3.30
Titanium.............................................................................0.65-1.15
Aluminum ..........................................................................0.20-0.80
Cobalt ...............................................................................1.00 max.
Carbon..............................................................................0.08 max.
Manganese .......................................................................0.35 max.
Silicon ...............................................................................0.35 max.
Phosphorus.....................................................................0.015 max.
Sulfur...............................................................................0.015 max.
Boron ..............................................................................0.006 max.
Copper..............................................................................0.30 max
| Density | 8.19g/cm³ | 0.296 lb/in³ |
| Melting point | 1260-1336 | 2437°F |
Inconel series
Customize size as below
|
Shape
|
Size(mm)
|
|
WIre
|
0.5-7.5
|
|
Rod/Bar
|
8.0-200
|
|
Strip
|
(0.5-2.5)*(5-180)
|
|
Tube
|
custom made
|
|
Plate
|
custom made
|
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
