Product Details
Place of Origin: China
Brand Name: Victory
Certification: CE
Model Number: Cr10Ni90
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 5
Packaging Details: Spool package with Carton box, Coil package with polybag for Resistance wire
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Material: |
Nickel, Chromium |
Nickel(Min): |
89% |
Tensile Strength: |
637MPA |
Magnetic Permeability: |
0.78+/-0.05 |
Elongtation: |
≥20% |
Application: |
Heating, Resistivity |
Condition: |
Hard / Soft |
Sureface: |
Bright, Oxided, Acide |
Delivery Time: |
7-20 Days |
Name: |
NiCr Alloy Wire |
Material: |
Nickel, Chromium |
Nickel(Min): |
89% |
Tensile Strength: |
637MPA |
Magnetic Permeability: |
0.78+/-0.05 |
Elongtation: |
≥20% |
Application: |
Heating, Resistivity |
Condition: |
Hard / Soft |
Sureface: |
Bright, Oxided, Acide |
Delivery Time: |
7-20 Days |
Name: |
NiCr Alloy Wire |
High-Temperature Resistance Of Cr10Ni90 Nichrome Alloy Wire For Industrial Furnaces And Heaters
Introduction:
Cr10Ni90 nickel-chromium alloy wire is a high-performance resistance heating material, mainly composed of 90% nickel and 10% chromium, with excellent high-temperature strength, oxidation resistance and corrosion resistance. The maximum operating temperature of this alloy wire can reach 1300℃, the melting point is about 1400℃, the density is 8.7 g/cm³, and the resistivity is 1.09±0.05 μΩ·m at 20℃. Its good ductility and welding properties make it easy to process into heating elements of different shapes. Cr10Ni90 alloy wire is widely used in industrial furnaces, heaters and other high-temperature equipment, especially suitable for use in high temperature and corrosive environments.
Applications:
Technical Parameters:
| Performance material | Cr10Ni90 | Cr20Ni80 | Cr30Ni70 | Cr15Ni60 | Cr20Ni35 | Cr20Ni30 | |
| Composición | Ni | 90 | Rest | Rest | 55.0～61.0 | 34.0～37.0 | 30.0～34.0 |
| Cr | 10 | 20.0～23.0 | 28.0～31.0 | 15.0～18.0 | 18.0～21.0 | 18.0～21.0 | |
| Fe | － | ≤1.0 | ≤1.0 | Rest | Rest | Rest | |
| Temperatura máxima℃ | 1300 | 1200 | 1250 | 1150 | 1100 | 1100 | |
| Punto de fusion ℃ | 1400 | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Densidad g/cm3 | 8.7 | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 | |
| Resistividad μΩ·m,20℃ | 0.76±0.05 | 1.09±0.05 | 1.18±0.05 | 1.12±0.05 | 1.00±0.05 | 1.04±0.05 | |
| Alargamiento a la ruptura | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 | |
| Calor especifico J/g.℃ | － | 0.44 | 0.461 | 0.494 | 0.5 | 0.5 | |
| Conductividad térmica KJ/m.h℃ | － | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
| Coeficiente de expansión de líneas a×10-6/(20～1000℃) | － | 18 | 17 | 17 | 19 | 19 | |
| Estructura micrográfica | － | Austenite | Austenite | Austenite | Austenite | Austenite | |
| Propiedades magnéticas | － | Nonmagnetic | Nonmagnetic | Nonmagnetic | Weak magnetic | Weak magnetic | |
| Form | Specification | |
| Wire | Diameter=0.025mm~8mm | |
| Flat wire | Width=0.40~6.0mm | Thick=0.03~0.50mm |
| Strip | width=8~250mm | Thick=0.05~3.0mm |
| Bar | Diameter=8~100mm | Long=50~1000 |
|
|
Service:
By choosing our NiCr alloy heaters, you gain access to a heating solution that combines efficiency, reliability, and flexibility. We are committed to delivering top-quality products and services that enhance your production efficiency and reduce energy consumption. With our heaters, you can expect outstanding performance and a customized approach to meet your heating needs.
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Size dimension range:
Wire: 0.01-10mm
Ribbons: 0.05*0.2-2.0*6.0mm
Strip: 0.05*5.0-5.0*250mm
NiCr series: Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30
Packing and Shipping:
Sturdy cardboard boxes are used for packaging NiCr Alloy.
Each box has dimensions of approximately 26 cm (length) x 26 cm (width) x 30 cm (height).
The shipping method for NiCr Alloy depends on the customer's requirements.
