Type K Mineral Insulated Armored Thermocouple RTD Cable with SS304/Inconel600 Sheath Material

MOQ:	5kg
Price:	$2.91
Delivery Period:	5-21 days
Payment Method:	L/C, D/A, D/P, Western Union, MoneyGram
Supply Capacity:	300 tons per month

Details Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Victory

Certification

CE,ROHS

Model Number

Mineral Insulated Cable

Document

Highlight:

SS304 Mineral Insulated Cable

Inconel600 Mineral Insulated Cable

Product Description

Key attributes

Industry-specific attributes

Application

Heating

Conductor Material

Copper Clad Aluminum

Conductor Type

Stranded

Insulation Material

Rubber

Other attributes

Place of Origin

Jiangsu, China

Brand Name

Victory

Model Number

Type K T N R S

Type

insulated

Product name

MI Cable

Application

Temperature Measuring

Dia(mm)

0.25mm to 12.7mm

Customized support

OEM, ODM

Insulator

99.6% high purity MgO

Core

2,4,6

Temperature range

0~1100(℃)

Size

Custom Size

Packing

Polyform+giftbox+export Carton

Delivery time

7-20 Days

Packaging and delivery

Selling Units:

Single item

Single package size:

25X25X12 cm

Single gross weight:

20.000 kg

Type K Mineral Insulated Armored Thermocouple RTD Cable with SS304/Inconel600 Sheath Material 0

Code	Wire Component of the thermocouple
	+Positive leg	- Negative Leg
N	Ni-Cr-Si(NP)	Ni-Si-magnesium (NN)
K	Ni-Cr(KP)	Ni-Al(Si) (KN)
E	Ni-Cr(EP)	Cu-Ni (EN)
J	Iron (JP)	Cu-Ni (JN)
T	Copper (TP)	Cu-Ni (TN)
B	Platinum Rhodium-30%	Platinum Rhodium -6%
R	Platinum Rhodium-13%	Platinum
S	Platinum Rhodium -10%	Platinum

Material	Type	Grade	Working temperature (deg)		Tolerance	Standard
			Long Term	Short Term
NiCr-NiSi	K	1	-40~1100	-40~1300	±1.5 deg	GB/T 2614-1998
		2			±2.5 deg
NiCr-CuNi	E	1	-40~800	-40~900	±1.5 deg	GB/T 4993-1998
		2			±2.5 deg
Fe-Constantan	J	1	-40~600	-40~800	±1.5 deg	GB/T 4994-1998
		2			±2.5 deg
Cu-CuNi	T	1	-200~300	-200~400	±0.5 deg	GB/T 2903-1998

Outer Sheath(mm)		core wire Dia.( mm)		Outer Sheath(mm)o core wire Dia.( mm)				Length(m)
Out Dia	Wall Thickness	K,N,E,J,T Types	S,R,B Types	K,N Types	E,J,T Types	S,R Types	B Types	Length(m)
0.5	0.05-0.10	0.08-0.12	...	SS304, SS321, SS316, SS310, INCL600	SS30, SS32, SS316	INCL60, INCL800	INCL60, INCL800	500
1.0	0.10-0.20	0.15-0.20	...					300
1.5	0.15-0.25	0.23-0.30	...					200
1.6	0.16-0.26	0.26-0.36	...					200
2.0	0.25-0.35	0.40-0.50	0.25-.030					180
3.0	0.38-0.48	0.50-0.60	0.30-0.40					80
3.2	0.48-0.58	0.58-0.68	0.30-0.40					75
4.0	0.52-0.62	0.60-0.70	0.35-0.40					70
4.8	0.73-0.83	0.75-0.85	0.40-0.45					40
5.0	0.78-0.88	0.80-0.90	0.40-0.45					40
6.0	0.98-1.08	0.90-1.10	0.45-0.50					30
6.4	1..05-1.15	1.02-1.12	0.45-0.50					30
8.0	1.30-1.44	1.30-1.40	0.45-0.50					20
12.7	1.75-1.90	1.95-2.05	...					10

Type K Mineral Insulated Armored Thermocouple RTD Cable with SS304/Inconel600 Sheath Material 1

Type K Mineral Insulated Armored Thermocouple RTD Cable with SS304/Inconel600 Sheath Material 2
