Product Details
Place of Origin: China
Brand Name: Victory
Certification: CE,ROHS,ISO 9001
Model Number: Inconel 825
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 5 Kg
Price: Negotiable
Packaging Details: Inconel 825 wire packed in Spool Carton box, Coil package with polybag,then in woodencase
Delivery Time: 5-21 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 tons per month
Product Name: |
Inconel 825 Wire |
Material: |
Ni Cr Fe |
Nickel(Min): |
38-46% |
Density: |
8.14 G/cm3 |
Melting Point: |
1370-1400°C |
Modulus Of Elasticity: |
196 GPa |
Thermal Conductivity: |
10.3 W/(m·K) |
Elongation (≥ %): |
45% |
Application: |
Oil And Gas Industry |
Sureface: |
Bright,Oxided |
Size: |
Customized |
Linear Expansion Coefficient: |
13.2 μm/m·K |
Yield Strength: |
345 MPa |
Tensile Strength: |
690 MPa |
Product Name: |
Inconel 825 Wire |
Material: |
Ni Cr Fe |
Nickel(Min): |
38-46% |
Density: |
8.14 G/cm3 |
Melting Point: |
1370-1400°C |
Modulus Of Elasticity: |
196 GPa |
Thermal Conductivity: |
10.3 W/(m·K) |
Elongation (≥ %): |
45% |
Application: |
Oil And Gas Industry |
Sureface: |
Bright,Oxided |
Size: |
Customized |
Linear Expansion Coefficient: |
13.2 μm/m·K |
Yield Strength: |
345 MPa |
Tensile Strength: |
690 MPa |
Introduction:
1. Inconel 825 wire is a nickel-iron-chromium alloy wire renowned for its remarkable corrosion resistance in diverse aggressive environments.
2. It finds extensive use in chemical processing, oil and gas, and marine industries due to its ability to resist oxidizing and reducing acids, including sulfuric, phosphoric, and nitric acids.
3. With its excellent corrosion resistance, Inconel 825 wire is commonly employed in heat exchangers, chemical processing equipment, and seawater handling systems.
4. It offers reliable performance and durability, as it can maintain its mechanical strength even in high-temperature environments.
Parameter:
Chemical composition:
Nickel (Ni): 38-46%
Chromium (Cr): 19.5-23.5%
Molybdenum (Mo): 2.5-3.5%
Copper (Cu): 1.5-3.0%
Physical properties:
Density: 8.14 g/cm³
Melting point: 1370-1400°C
Modulus of elasticity: 196 GPa
Thermal conductivity: 10.3 W/(m·K) (room temperature)
Linear expansion coefficient: 13.2 μm/m·K (room temperature)
Mechanical behavior:
Yield strength: 345 MPa (room temperature)
Tensile strength: 690 MPa (room temperature)
Elongation: 45% (room temperature)
|
Chemical Composition (%)
|
||||||||||
|
C
|
Si
|
Mn
|
S
|
Mo
|
Ti
|
Cr
|
Ni
|
Al |
Fe
|
Cu
|
|
≤0.05
|
≤0.50
|
≤1.00
|
≤0.03
|
≤2.5~3.5
|
≤0.6~1.2
|
19.5~23.5
|
38.0~46.0
|
≤0.2 |
≥22.0
|
1.5~3.0
|
|
Standard
|
|||
|
Sheet/Plate
|
Round bar/Wire
|
Pipe
|
Tube
|
|
ASME SB-424
ASME SB-906
|
ASME SB-425
|
ASME SB-423
ASME SB-829
ASME SB-163
ASME SB-751
ASME SB-775
|
ASME SB-704
ASME SB-705 ASME SB-751 ASME SB-775 |
|
|
|||||||||||||
| Specification | Title |
| B163 | Seamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes |
| B423 | Nickel-Iron-Chromium-Molybdenum-Copper Alloy (UNS N08825 and N08221)* Seamless Pipe and Tube |
| B424 | Ni-Fe-Cr-Mo-Cu Alloy (UNS N08825 and UNS N08221)* Plate, Sheet, and Strip |
| B425 | Ni-Fe-Cr-Mo-Cu Alloy (UNS N08825) |
| B704 | Welded UNS N06625 and UNS N08825 Alloy Tubes |
| B705 | Nickel-Alloy (UNS N06625 and N08825) Welded Pipe |
| B751 |
General Requirements for Nickel and Nickel Alloy Welded Tube |
contact us
email:victory@dlx-alloy.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Characteristic:
Advantage:
Application:
Overall, Inconel 825 alloy wire is an ideal material choice in the oil and gas industry to meet the challenges of corrosive media, high temperature and high pressure environments. Its corrosion resistance, high temperature stability and resistance to stress corrosion cracking make it a reliable material for critical components and equipment.
|
|
Q & A:
Q1: What are the main advantages of Inconel 825 wire?
A1: Inconel 825 wire offers exceptional corrosion resistance in a wide range of aggressive environments and is particularly well-suited for applications involving acids, such as sulfuric acid and phosphoric acid.
Q2: What industries commonly utilize Inconel 825 wire?
A2: Inconel 825 wire is commonly used in industries such as chemical processing, oil and gas, and marine, where corrosion resistance is crucial, and it finds applications in equipment such as heat exchangers, chemical processing equipment, and seawater handling systems.
