CuNi Copper Nickel CuNi1 Alloy Electric Heating Ribbon Wire With Low Resistance

MOQ:	5
Standard Packaging:	Spool package with Carton box, Coil package with polybag
Delivery Period:	5-21 days
Payment Method:	L/C, T/T, Western Union, MoneyGram
Supply Capacity:	300 tons per month

Details Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Victory

Certification

CE,ROHS,ISO 9001

Model Number

CuNi23、CuNi30、CuNi34、6J8、6J11

Document

Product Name:

CuNi Wire

Nickel(Min):

Resistivity:

Tensile Strength:

420 MPA

Density:

8.9 G/cm3

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright

Delivery Time:

7-20 Days

Maximum Temperature:

Melting Point:

1100℃

Highlight:

CuNi44 Copper Nickel Strip

CuNi2 Copper Nickel Strip

CuNi6 nickel plated copper strip

Product Description

Cuni is a type of resistance alloy, which is made up of copper and nickel as the main components. It has a low temperature coefficient of resistance (TCR), and a wide operating temperature range. It has good properities on mechanical working, low electric resistance, good heat-resistant and corrosion-resistant, easy to be processed and lead welded. It is used to make the key components in the thermal overload relay, low resistance thermal circuit breaker, and the electrical appliances. It is also an important material for electrical heating cable.

Cu-Ni Alloy: CuNi1,CuNi2,CuNi6,CuNi8, CuNi10, CuNi14, CuNi19,CuNi23,CuNi30,CuNi34, CuNi44
NC003, NC005, NC010, NC012, NC015, NC020, NC025, NC030, NC035, NC040, NC050
We can supply type of : wire, ribbon,strip, customized furnace spring wire/strip
Cold Drawing Wire: DIA 0.03m-8.0mm
Hot Rolled Rod / Bar: DIA 8.0mm-50.0mm
Cold Rolled Ribbon/Strip: (0.05mm-0.35mm) *(0.5-6.0)mm

Properties/ Material	Resistivity (200C μΩ.m)	Max. Working Temperature(C)	Tensile Strength (Mpa)	Melting Point	Density(g/cm3)
NC003(CuNi1)	0.03	200	210	1085	8.9
NC005(CuNi2)	0.05	200	220	1090	8.9
NC010(CuNi6)	0.1	220	250	1095	8.9
NC012(CuNi8)	0.12	250	270	1097	8.9
NC015(CuNi10)	0.15	250	290	1100	8.9
NC020(CuNi14)	0.2	300	310	1115	8.9
NC025(CuNi19)	0.25	300	340	1135	8.9
NC030(CuNi23)	0.3	300	350	1150	8.9
NC035(CuNi30)	0.35	350	400	1170	8.9
NC040(CuNi34)	0.4	350	400	1180	8.9
NC050(CuNi44)	0.5	400	420	1200	8.9

Shape	Size(mm)
Wire	0.05-7.5
Rod	8-50
Ribbon	(0.05-0.35)*(0.5-6.0)
Strip	(0.5-2.5)*(5-40)
